Automatic Divider Curtain with Overheating Protection and 7.5m per Minute Speed for Sports Halls with 2 Years Warranty

브랜드 이름:	FLYON
모델 번호:	스포츠 홀 분할 커튼
모크:	100
가격:	AED 287.92-317.83

자세한 정보

제품 설명

자세한 정보

원래 장소:

중국 광둥

재료:

고강도 폴리에스터 섬유 또는 유리 섬유 fabric+PVC

두께:

2.3mm

모터 전압:

220V AC

모터 유형:

관형 모터

모터 파워:

100Nm

작동 속도:

분당 7.5m

겹쳐 쌓이는 차원:

50cm

모터 직경:

3 피트

최대 커튼 면적:

125m²

최대 커튼 길이:

20 Ｍ

모터 단계:

단일-위상

과부하 보호:

자동 리셋, 열 과부하 보호

제어 옵션:

키 스위치, 무선 리모컨

이음새 유형:

수평 솔기

하단 튜브:

패딩 처리된 바닥 튜브

강조하다:

Automatic Overheating Protection Divider Curtain

7.5m per Minute Dividing Curtain

2 Years Warranty Sports Hall Divider

제품 설명

Automatic Center Roll Divider Curtains for Sports Facilities

The Center Roll Divider features an innovative overhead design that eliminates traditional hoist cables, straps, and overhead support rollers. With minimal stack height, this system provides efficient space utilization in gymnasium environments.

As the aluminum drive tube rotates, it smoothly moves the curtain upward, rolling both top and bottom sections compactly toward the ceiling. This design eliminates common wear points found in traditional dividers and enables the Center-Roll system to operate twice as fast as standard curtain systems.

The assembly operates with minimal noise and includes automatic overheating protection. Permanently lubricated components ensure maintenance-free operation. When mounted directly to roof structures, this divider maintains a stack dimension within 50cm of the ceiling, maximizing clearance space.

The system achieves fast folding action at 7.5 meters per minute and is available in solid, mesh, or combination configurations to suit various facility requirements.

Product Specifications

Item	Value
Place of Origin	China
Product Name	Sports Hall Dividing Curtains
Color	Customizable
Brand	Flyon
Material	High-strength polyester fiber or glass fiber fabric with PVC coating
Suitable Places	Gymnasium, schools, basketball courts

Motor System

Utilizes 100 Nm, 220 V AC tubular motors with 3-foot diameter. The tubular-type motor (220V, single-phase) includes gear reducer and brake mechanism concealed within the horizontal batten tube. Each motor is equipped with up/down push-button limit switches and automatic reset thermal overload protection.

Motor Configuration

Curtains up to 125 m² or 20 meters long utilize single motor operation. Larger curtain systems employ two synchronized motors for consistent performance. Standard operation includes key switch control with optional wireless remote capability.

Performance Specifications

Typical stacking dimension is approximately 50 cm. The curtain raises or lowers at a rate of approximately 7.5 meters per minute for efficient operation.

Available Configurations

Solid and Mesh: Combination design with padded bottom tube
All Solid: Complete solid construction with padded bottom tube
All Mesh: Full mesh design with padded bottom tube

Available in wide variety of vinyl and mesh colors to match facility aesthetics.

Design Features

Horizontal seams ensure smooth rolling action and consistent performance throughout the system's operation.

Certifications

Packaging & Shipping

Company Profile

Flyon has specialized in EPDM and SBR granules production for over ten years, bringing extensive manufacturing expertise to our sports facility products.

Frequently Asked Questions

What is your delivery time?

We offer flexible delivery schedules. In-stock items ship within 5 working days, while mass production orders require 25-35 working days.

Can you provide warranty?

Yes! We provide 5 years quality warranty and 10 years backup support for all our products.

Can I get your samples?

Yes! Flyon Sports offers free samples for our customers, with approximately 3 days preparation time.

Do you provide OEM service?

Yes! We provide comprehensive OEM and ODM services to meet your specific requirements.

Contact Information

Website: www.flyonsports.cn

Address: 406 Room B#2013 Creative Marker Park, Lijia Road 108th LongGang District Shenzhen, China

WhatsApp: +86 13534071985

Email: Info@flyonsport.com
