제품 세부 정보

Created with Pixso. 집 Created with Pixso. 제품 Created with Pixso.
분리 커튼
Created with Pixso.

Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation

Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation

Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation

브랜드 이름: FLYON
모델 번호: 스포츠 홀 분할 커튼
모크: 100
가격: $77-85
자세한 정보
제품 설명
자세한 정보
원래 장소:
중국 광둥
재료:
고강도 폴리에스터 섬유 또는 유리 섬유 fabric+PVC
모터 유형:
관형 모터(220V, 단상)
모터 파워:
100Nm
모터 전압:
220V AC
모터 직경:
3 피트
작동 속도:
분당 7.5m
겹쳐 쌓이는 차원:
50cm
최대 길이:
20 Ｍ
최대 면적:
125m²
모터 동기화:
더 큰 커튼을 위한 두 개의 동기화된 모터
작동 제어:
키 스위치 및 무선 리모컨
과열 보호:
오토매틱
하단 튜브:
패딩 처리된
이음새 유형:
수평 솔기
롤링 액션:
매끄러운
강조하다:

Customized Color Divider Curtain

,

High-Strength Polyester Fiber Dividing Curtain

,

7.5m per Minute Sports Hall Divider Net

제품 설명
High-Quality Sports Hall Divider Net for Stadium Ground Division Curtain
Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 0
The Center Roll Divider offers a simple overhead design for gymnasiums, eliminating hoist cables, straps, and overhead support rollers while maintaining minimal stack height.
As the aluminum drive tube rotates, it moves the curtain up, rolling both top and bottom sections neatly and compactly to the ceiling. This design eliminates wear points experienced with other dividers and allows the Center-Roll to operate twice as quickly as standard curtains.
The assembly operates extremely quietly, features automatic overheating protection, and is permanently lubricated for maintenance-free operation. When directly attached to the roof structure, this divider provides a stack dimension within 50cm of the ceiling for maximum clearance.
This fast folding action is achieved at 7.5m per minute. Available in solid and mesh, all solid, or all mesh finish configurations.
Product Specifications
ItemValue
Place of OriginChina
Product NameSports Hall Dividing Curtains
ColorCustomizable
BrandFlyon
MaterialHigh-strength polyester fiber or glass fiber fabric + PVC
Suitable PlacesGymnasium, school, and basketball court
Motor System Details
Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 1
Uses 100 Nm, 220 V AC tubular motor(s), 3 feet in diameter.
Tubular-type motor (220V, single-phase) with gear reducer and brake mechanism concealed inside the horizontal batten tube. Motor is equipped with up and down push-button type limit switches and an automatic reset thermal overload protection.
Motor Configuration
Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 2
Curtains up to 125 m² or 20 m long use single motor. Larger curtains use two synchronized motors.
Includes key switch operation standard. Also available with wireless remote control.
Performance Specifications
Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 3
Typical stacking dimension is approximately 50 cm. Curtain raises or lowers at a rate of approximately 7.5m per minute.
Available Configurations
Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 4
Available in a wide variety of vinyl and mesh colors:
  • Solid and Mesh: Solid and Mesh with Padded Bottom Tube
  • All Solid: All Solid with Padded Bottom Tube
  • All Mesh: All Mesh with Padded Bottom Tube
Construction Features
Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 5 Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 6
Horizontal seams allow smooth rolling action for optimal performance.
Quality Certifications
Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 7 Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 8 Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 9
Packaging & Shipping
Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 10 Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 11 Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 12 Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 13 Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 14 Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 15
Company Introduction
Flyon has specialized in EPDM and SBR granules production for more than ten years, bringing extensive expertise to sports facility solutions.
Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 16 Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 17 Customized Color High-Strength Polyester Fiber Sports Hall Divider Net with 7.5m per Minute Operation 18
Frequently Asked Questions
What is your delivery time?
We have flexible delivery time. For in stock and mass production, it is about 5 working days and 25-35 working days respectively.
Can you provide warranty?
Yes! We provide 5 years' quality warranty and 10 years' backup support.
Can I get your samples?
Yes! Flyon Sports offers free samples for our customers, about 3 days for preparation.
Do you provide OEM service?
Yes! We provide OEM and ODM service.
Contact Information
Website: www.flyonsports.cn
Address: 406 Room B#2013 Creative Marker Park, Lijia Road 108th LongGang District Shenzhen, China
Whatsapp: +86 13534071985
Email: Info@flyonsport.com
